MT9D131: 1/3.2-Inch 2-Mp SOC Digital Image Sensor
Architecture Overview
Color Pipeline
Figure 5:
Color Pipeline
DATA, S YN C IN
Test Pattern
Bla c k Level S u b tra c tion
Di g ital G ain
Lens S ha d in g C orre c tion
with Di g ital G ain
Line Buffers
Defe c t C orre c tion
Interpolation an d
E dg e Dete c tion
MEA S UREMENT EN G INE
AE S tatisti c s
CC M an d Aperture
C orre c tion
G amma C orre c tion
YUV Pro c essin g
De c imator
YUV-to-R G B/YUV C onversion
Format Output
DATA, S YN C OUT
Test Pattern
During normal operation of MT9D131, a stream of raw image data from the sensor core
is continuously fed into the color pipeline. For test purposes, this stream can be
replaced with a fixed image generated by a special test module in the pipeline. The mod-
ule provides a selection of test patterns sufficient for basic testing of the pipeline.
PDF: 09005aef824c90ce/Source: 09005aef824c90d6
MT9D131_LDS_2.fm - Rev. B 3/07 EN
7
Micron Technology, Inc., reserves the right to change products or specifications without notice.
?2006 Micron Technology, Inc. All rights reserved.
